KM Bearing Lock Nuts Steel, Plain Finish, Flat Design

KM Steel Bearing Lock Nuts, Plain Finish, Flat Design sketch

Hide technical drawing

Part Options / Table

Part Number	Size	d₁	d₂	d₃	b	h	t	Part number bearing lock washer	Part number hook spanner wrench

KM-0	0	M 10 x 0.75	0.71	0.53	0.12	0.16	0.08	MB-0	1810-A16-20
KM-1	1	M 12 x 1	0.87	0.67	0.12	0.16	0.08	MB-1	1810-A16-20
KM-2	2	M 15 x 1	0.98	0.83	0.16	0.20	0.08	MB-2	1810-A25-28
KM-3	3	M 17 x 1	1.10	0.94	0.16	0.20	0.08	MB-3	1810-A25-28
KM-4	4	M 20 x 1	1.26	1.02	0.16	0.24	0.08	MB-4	1810-A30-32
KM-5	5	M 25 x 1.5	1.50	1.26	0.20	0.28	0.08	MB-5	1810-A34-36
KM-6	6	M 30 x 1.5	1.77	1.50	0.20	0.28	0.08	MB-6	1810-A45-50
KM-7	7	M 35 x 1.5	2.05	1.73	0.20	0.31	0.08	MB-7	1810-A52-55
KM-8	8	M 40 x 1.5	2.28	1.97	0.24	0.35	0.10	MB-8	1810-A58-62
KM-9	9	M 45 x 1.5	2.56	2.20	0.24	0.39	0.10	MB-9	1810-A65-70
KM-10	10	M 50 x 1.5	2.76	2.40	0.24	0.43	0.10	MB-10	1810-A68-75

Show / Hide columns

Metric

Dimensions in: Inch (change to Metric)

Size	d₁	d₂	d₃	b	h	t	Part number bearing lock washer	Part number hook spanner wrench

0	M 10 x 0.75	0.71	0.53	0.12	0.16	0.08	MB-0	1810-A16-20
1	M 12 x 1	0.87	0.67	0.12	0.16	0.08	MB-1	1810-A16-20
2	M 15 x 1	0.98	0.83	0.16	0.20	0.08	MB-2	1810-A25-28
3	M 17 x 1	1.10	0.94	0.16	0.20	0.08	MB-3	1810-A25-28
4	M 20 x 1	1.26	1.02	0.16	0.24	0.08	MB-4	1810-A30-32
5	M 25 x 1.5	1.50	1.26	0.20	0.28	0.08	MB-5	1810-A34-36
6	M 30 x 1.5	1.77	1.50	0.20	0.28	0.08	MB-6	1810-A45-50
7	M 35 x 1.5	2.05	1.73	0.20	0.31	0.08	MB-7	1810-A52-55
8	M 40 x 1.5	2.28	1.97	0.24	0.35	0.10	MB-8	1810-A58-62
9	M 45 x 1.5	2.56	2.20	0.24	0.39	0.10	MB-9	1810-A65-70
10	M 50 x 1.5	2.76	2.40	0.24	0.43	0.10	MB-10	1810-A68-75

Build & Price

Selected Part

Part Number

Total (net)

Can$3.90

In Stock: 10

In Stock

Quantity

Create Project List

Save as Favorites

Please note our quantity discounts (Canadian Dollars).

Min	Max	Price
1	49	Can$3.90
50	99	Can$3.57
100	249	Can$3.25
≥ 250		Can$2.92

Prop 65: Not compliant

WARNING:
Cancer and Reproductive Harm - www.P65Warnings.ca.gov

RoHS: Compliant

This article is RoHS-compliant in application of Annex III., which means it complies with EU Directive 2011/65/EU, including extension (2015/863/EU), for restricting the use of certain hazardous substances in electrical and electronic devices. The Directive regulates the use of hazardous substances in devices and components. The implementation in national law is summarily described with RoHS(Restriction of (the use of certain) hazardous substances)).

Weight: -

If the weight is not listed, please contact our Sales Department for more information.
